QINGONG QG-N16 MINI EXCAVATOR
Engine Model Laidong 385
Engine Type 3-cylinder, inline, water-cooled, 4-stroke
Displacement 1.6 L
Max. Power 29 kW / 3200 rpm
Horsepower 38 HP
Fuel Type Diesel
Fuel Consumption 285 g/kWh
Fuel Tank Capacity 20 L
Bucket Capacity 0.03 m³
Overall / Packing Dimensions 3250 × 1100 × 2300 mm
Track Ground Length 1200 mm
Track Width 180 mm
Max. Digging Depth 1800 mm
Max. Dumping Height 1850 mm
Max. Digging Height 2680 mm
Gradeability 30°
Travel Speed 0–3 km/h
Bucket Digging Force 16 kN
=
