QINGONG QG-N25 MINI EXCAVATOR
Engine Brand：Yammar-3TNY80F
Travel Speed Low/High (km/h)：0-1.8
Gradeability (%)：15
Side Swing Angle (Left/Right)：45°
Maximum Power (kW)：14.6
Maximum Rotational Speed (rpm)：2400
Number of Cylinders：3
Cooling Method：water-cooled
Engine Oil Capacity for Replacement (L)：1.1
Fuel Type：Diesel
Fuel Grade：No.5 / -0
Theoretical Fuel Consumption (L/h)：0.5-1.2
Rated Set Pressure (MPa)：24.5
Maximum Flow Rate of Main Pump (L/min)：32
Fuel Tank Capacity (L)：31.5
Hydraulic Oil Tank Capacity (L)：29
Operating Weight of Machine (kg)：3000
Maximum Digging Height (mm)：4155
Maximum Dumping Height (mm)：2840
Maximum Digging Depth (mm)：2456
Maximum Digging Radius (mm)：4520
Overall Length (mm)：4077
Overall Width (mm)：1500
Overall Height (mm)：2450
