Performance Operating weight: 5100 kg Rated load: 1500 kg Bucket capacity: 0.75 m³ Max Speed: 12/18 km/h Max traction: ＞32 kN Max breakout: ≥22 kN Lifting time of boom: 7 s
Engine Model: Weichai WP4.1 Rated power: 103 kW / 2300 rpm Engine displacement: 4.088 L Emission Standard: National III
Dimension Overall operating height: 4070 mm Height to bucket hinge pin: 3150 mm Height to top of cab: 2160 mm Height to bottom of level bucket: 2983 mm Without bucket length: 3000 mm Overall length with bucket: 3795 mm Dumping angle at maximum height: 40° Dumping height: 2450 mm Dumping reach: 700 mm Rollback of bucket on ground: 30° Rollback of bucket at full height: 104° Wheelbase: 1500 mm Ground clearance: 200 mm Angle of departure: 20° Front turning radius without bucket: 1365 mm Front turning radius: 2200 mm Rear turning radius: 1742 mm Rear axle to bumper: 938 mm Tread width: 1674 mm Width: 2124 mm Bucket width: 2134 mm
