Performance Operating weight: 3000 kg Rated load: 700 kg Bucket capacity: 0.3 m³ Max Speed: 10 km/h Max traction: ≥25.40 kN Max breakout: ≥18.4 kN Lifting time of boom: 7 s
Engine Manufacturer: Xinchai Model: C490BPG Rated power: 36.7 kW / 2650 rpm Engine displacement: 2.27 L Emission Standard: National II
Dimension Overall operating height: 3350 mm Height to bucket hinge pin: 2450 mm Height to top of cab: 2050 mm Height to bottom of level bucket: 2285 mm Without bucket length: 2300 mm Overall length with bucket: 2950 mm Dumping angle at maximum height: 40° Dumping height: 2100 mm Dumping reach: 690 mm Rollback of bucket on ground: 30° Rollback of bucket at full height: 104° Wheelbase: 1240 mm Ground clearance: 140 mm Angle of departure: 20° Front turning radius without bucket: 1310 mm Front turning radius: 1881 mm Rear turning radius: 1264 mm Rear axle to bumper: 594 mm Tread width: 1102 mm Width: 1402 mm Bucket width: 1500 mm
