Operating weight: 3300 kg Rated load: 700 kg Bucket capacity: 0.4 m³ Max Speed: 12 km/h Max traction: ≥25.40 kN Max breakout: ≥18.4 kN Lifting time of boom: 7 s
Manufacturer: Xinchai Engine Model: C490BPG Rated power: 36.7 kW / 2650 rpm Engine displacement: 2.27 L Emission Standard: China Stage II
Overall operating height: 4100 mm Height to bucket hinge pin: 3090 mm Height to top of cab: 2113 mm Height to bottom of level bucket: 2910 mm Without bucket length: 2638 mm Overall length with bucket: 3466 mm Dumping angle at maximum height: 40° Dumping height: 2250 mm Dumping reach: 800 mm Rollback of bucket on ground: 30° Rollback of bucket at full height: 100° Wheelbase: 1075 mm Ground clearance: 180 mm Angle of departure: 20° Front turning radius without bucket: 1300 mm Front turning radius: 2290 mm Rear turning radius: 1440 mm Rear axle to bumper: 1080 mm Tread width: 1450 mm Width: 1720 mm Bucket width: 1740 mm
