Performance Operating weight: 4200 kg Rated load: 1000 kg Bucket capacity: 0.5 m³ Max Speed: 12/18 km/h Max traction: ≥28.2 kN Max breakout: ≥20 kN Lifting time of boom: 7 s
Engine Manufacturer: Xinchai Model: A498BZG/T Rated power: 55 kW / 2500 rpm Engine displacement: 3.17 L Emission Standard: National II
Dimension Overall operating height: 3871 mm Height to bucket hinge pin: 2900 mm Height to top of cab: 2150 mm Height to bottom of level bucket: 2730 mm Without bucket length: 2750 mm Overall length with bucket: 3500 mm Dumping angle at maximum height: 40° Dumping height: 2230 mm Dumping reach: 715 mm Rollback of bucket on ground: 30° Rollback of bucket at full height: 104° Wheelbase: 1500 mm Ground clearance: 200 mm Angle of departure: 20° Front turning radius without bucket: 1298 mm Front turning radius: 2010 mm Rear turning radius: 1714 mm Rear axle to bumper: 890 mm Tread width: 1462 mm Width: 1782 mm Bucket width: 1830 mm
