Operating weight: 3460 kg
Rated load: 1050 kg
Bucket capacity: 0.5 m³
Max Speed: 12 km/h
Max traction: ≥28.2 kN
Max breakout: ≥20 kN
Lifting time of boom: 7 s
Manufacturer: Xinchai
Engine Model: A498BZG/T
Rated power: 55kW/2500rpm
Engine displacement: 3.17 L
Emission Standard: National‑II
Overall operating height: 4290 mm
Height to bucket hinge pin: 3278 mm
Height to top of cab: 2160 mm
Height to bottom of level bucket: 2983 mm
Without bucket length: 2770 mm
Overall length with bucket: 3490 mm
Dumping angle at maximum height: 40°
Dumping height: 2500 mm
Dumping reach: 700 mm
Rollback of bucket on ground: 30°
Rollback of bucket at full height: 104°
Wheelbase: 1115 mm
Ground clearance: 205 mm
Angle of departure: 20°
Front turning radius without bucket: 1250 mm
Front tuning radius: 2112 mm
Rear tuning radius: 1774 mm
Rear axle to bumper: 1082 mm
Tread width: 1500 mm
Width: 1880 mm
Bucket width: 1880 mm
